1039-CW9166
Steel Recessed Suspended Ceiling Access Point Installation Kit, Panel Bridge with Cisco CW9164/CW9166 Access Point Trim
| Access Point Vendor | Cisco |
| Access Point Model | CW9166i, CW9164i |
Product Description
Suspended ceiling mounting kit for most vendors' Wi-Fi APs. A cutout is made in the ceiling tile, the tile bridge is placed above the ceiling tile, and the AP is attached to the white trim. The AP and trim assembly is then drawn into the tile bridge with a wing nut, with only the front face of the AP exposed for optimal wireless coverage.
Key Features and Benefits
- Economical and easy to install
- Conveniently and quickly install APs and antennas from most vendors into 24 in. wide suspended ceiling tiles
- AP mounts flush to the ceiling, providing an aesthetic, professionally installed appearance
- 16 ga. galvanized steel tile bridge and support wire prevent ceiling tile sag or cracking
Technical Specifications
- Design: Recessed installation kit for installing Wi-Fi APs in 24 in. wide suspended ceiling tiles. Comprised of steel ceiling tile bridge, support wire, AP bracket, and trim for AP from leading vendors
- Performance: Designed to meet NEC300-22 and 300-23 for plenum installations
- Wi-Fi AP trim attaches with wing nuts
- Construction: 16 ga. galvanized steel tile bridge, all metal bracket and trim
- Use included support wire to attach to building structure
- Size: 23.375 x 3 x 3 in. (594 x 76 x 76mm)
- Suitable for both North American and European (metric) sized ceilings
Product Includes:
- (1) Galvanized steel ceiling tile bridge
- (1) AP specific bracket and trim
- (2) Grid Wires
- Required Hardware
- Installation instructions
Access Point Vendor
- Cisco
Access Point Model
- CW9166i
- CW9164i
Product Information
CW9166 Installation Guide and Product Specifications
The Oberon® In-Plane™ Recessed Mounts 1039 - 1039-CW9166 provide a reliable solution for installing Cisco CW9166i and CW9164i access points in suspended ceiling tiles. This kit ensures a flush, aesthetic finish while optimizing wireless coverage. It includes all necessary components for straightforward setup.
Key features include an economical design and easy installation process, making it ideal for enterprise environments. The 16 ga. galvanized steel tile bridge prevents ceiling sag or cracking, enhancing durability. Support wires attach to building structures for added stability and compliance.
Installation involves creating a cutout in the ceiling tile and placing the tile bridge above it. The access point and trim assembly are then secured with wing nuts, drawing everything into place. This method ensures only the front face of the AP is exposed for optimal performance.
Technical specifications cover a size of 23.375 x 3 x 3 inches (594 x 76 x 76 mm), suitable for North American and European ceilings. The design meets NEC 300-22 and 300-23 standards for plenum installations. Construction uses all-metal brackets and trim for long-lasting use.
Overall, this Oberon mount offers a professional appearance and efficient installation for network teams. It supports various applications in data centers, educational facilities, and healthcare settings. The included installation guide simplifies the process for quick deployment.
