EA-3401-C
Monitored eConnect PDU; Black; Horizontal 2U; C20 to L5-20 Input; (24) 5-20 Outlets; 1.9kW; 149°F (65°C); Secure Array IP Consolidation; Field-Replaceable Controller; +/-1% Metering Accuracy; 10/100/1000MB Port; Onboard GUI; SNMPv1/v2/v3; RESTful API; CLI; LDAP or RADIUS Integration; HTTPS; Environmental Sensor and Electronic Lock Integration Ready
| Plug | C20 Inlet to NEMA L5-20P |
| Outlets | (24) 5-20 Standard Outlets |
| Volts | 120V |
| Phase | Single-Phase |
| Input Current | 20A |
| kW Capacity | 1.9kW |
| Cabinet Compatibility | 2U or Higher |
| Color | Black |
Product Description
Monitored eConnect® PDUs provide remote power monitoring to the input and branch circuit level, making it possible to obtain and manage power consumption at the cabinet level.
Key Features and Benefits
- Reduced Networking Costs and Complexity – Secure Array® allows the use of a single IP address for up to 48 connected PDUs (32 when electronic locks are integrated). Second IP address for the entire array provides failover capability.
- Resistance to High Temperature – Marketleading temperature ratings of up to 149°F (65°C) ensures reliability when mounted toward hot aisles.
- Simplified Load Balancing – Phase-balance outlets on three-phase models ensure equal loading across all phases; allows use of shorter equipment power cords for better cable and airflow management.
- No Accidental Disconnections – Patented, low-profile locking outlets prevent accidental disconnections without requiring special cords
- Easy Identification of Failover Unit – Redundancy Pack includes 2 PDUs (one in Black and one in Glacier White) for easy identification of the primary and secondary unit.
- Electronic Lock Integration – Patented technology seamlessly integrates PDU, environmental sensors and electronic locks into a single hardware and software solution
- Gigabit Ethernet – Ensures compatibility with enterprise routers and switches.
- Latest UL Compliance – Meets UL and IEC 62368 for compliance with new listing requirements for North America and the European Union.
- Cabinet Preinstallation – Complete ecosystem ships ready for IT equipment integration, and saves deployment time and reduces packaging waste.
- High Power Configurations – Configurations supporting up to 100A Input provide an optimized solution for GPU & AI based applications. 30A branch circuit breakers provide flexibility when plugging high power IT equipment.
- Universal Input – A single PDU design with detachable input cords supports global AC power standards, streamlining procurement, reducing inventory complexity, accelerating deployment, and ensuring reliable high-power performance across worldwide data centers.
Product Information
Remote Power Monitoring Features of the Monitored eConnect PDU
The Monitored eConnect® PDU EA‑3401‑C delivers precise power distribution while providing built‑in monitoring capabilities. Designed for 2U or higher enclosures, it fits seamlessly into modern data‑center racks. Its robust construction supports reliable operation in demanding environments. With remote power monitoring, administrators can view voltage, current, and energy usage for each outlet from a centralized dashboard. The device reports real‑time data via SNMPv1/v2/v3, a RESTful API, and an onboard GUI, enabling proactive capacity planning. Integrated LDAP or RADIUS authentication ensures secure access to power metrics. The Secure Array® IP consolidation technology allows up to 48 PDUs to share a single IP address, simplifying network design and reducing cabling complexity. Failover is provided by a secondary address that automatically takes over if the primary link is lost. This streamlined architecture lowers operational costs while maintaining high availability. Engineered to operate at temperatures up to 149 degreesF (65 degreesC), the high temperature PDU meets the needs of hot‑aisle deployments and dense GPU workloads. Thermal‑resistant components protect the internal circuitry from overheating, ensuring consistent performance. Users benefit from reduced downtime and extended equipment lifespan. Compatibility with eConnect® Power IQ software provides advanced analytics and automated alerts for power anomalies. The PDU's field‑replaceable controller allows quick upgrades without removing the unit from the rack. Combined with CPI's global support network, the Monitored eConnect® PDU offers a future‑ready solution for AI, HPC, and enterprise workloads.
