EA-3440-E
Monitored eConnect PDU; Glacier White; 2U; L21-30 Input; Locking (24) C13 Outlets; 8.6kW; 149°F (65°C); Secure Array IP Consolidation; Field-Replaceable Controller; +/-1% Metering Accuracy; 10/100/1000MB Port; Onboard GUI; SNMPv1/v2/v3; RESTful API; CLI; LDAP or RADIUS Integration; HTTPS; Environmental Sensor and Electronic Lock Integration Ready; 100% Rated Hydraulic Magnetic Breakers
| Plug | NEMA L21-30P |
| Outlets | (24) C13 Locking Outlets |
| Volts | 120/208V |
| Phase | Three-Phase |
| Input Current | 30A |
| kW Capacity | 8.6kW |
| Cabinet Compatibility | 2U or Higher |
| Color | Glacier White |
Product Description
Monitored eConnect® PDUs provide remote power monitoring to the input and branch circuit level, making it possible to obtain and manage power consumption at the cabinet level.
Key Features and Benefits
- Reduced Networking Costs and Complexity – Secure Array® allows the use of a single IP address for up to 48 connected PDUs (32 when electronic locks are integrated). Second IP address for the entire array provides failover capability.
- Resistance to High Temperature – Marketleading temperature ratings of up to 149°F (65°C) ensures reliability when mounted toward hot aisles.
- Simplified Load Balancing – Phase-balance outlets on three-phase models ensure equal loading across all phases; allows use of shorter equipment power cords for better cable and airflow management.
- No Accidental Disconnections – Patented, low-profile locking outlets prevent accidental disconnections without requiring special cords
- Easy Identification of Failover Unit – Redundancy Pack includes 2 PDUs (one in Black and one in Glacier White) for easy identification of the primary and secondary unit.
- Electronic Lock Integration – Patented technology seamlessly integrates PDU, environmental sensors and electronic locks into a single hardware and software solution
- Gigabit Ethernet – Ensures compatibility with enterprise routers and switches.
- Latest UL Compliance – Meets UL and IEC 62368 for compliance with new listing requirements for North America and the European Union.
- Cabinet Preinstallation – Complete ecosystem ships ready for IT equipment integration, and saves deployment time and reduces packaging waste.
- High Power Configurations – Configurations supporting up to 100A Input provide an optimized solution for GPU & AI based applications. 30A branch circuit breakers provide flexibility when plugging high power IT equipment.
Product Information
Key Benefits of Monitored eConnect® PDU
The eConnect® EA-3440-E delivers precise power monitoring at the cabinet level, giving data center operators real‑time insight into energy use. Its 2U form factor fits seamlessly into standard racks while maintaining a clean, Glacier White appearance. Built to meet the demands of modern AI and HPC workloads, this unit supports reliable power distribution across critical infrastructure. As a true Power Distribution Unit, the EA-3440-E provides three‑phase capability and branch‑circuit level metering, enabling accurate PDU monitoring for load balancing and capacity planning. The device features +/-1 % metering accuracy and a Gigabit Ethernet port for fast network integration. By consolidating power management into a single chassis, it reduces networking complexity and overall cost of ownership. Electronic locks are integrated directly into each locking outlet, preventing accidental disconnections while supporting secure access control policies. The patented low‑profile locking outlets meet the needs of high‑density environments and simplify cable management. Compatibility with LDAP or RADIUS allows seamless authentication for authorized personnel. Environmental sensors can be added to the eConnect® platform, delivering temperature, humidity, and door status data to a unified monitoring dashboard. Sensor data is exposed via SNMPv1/v2/v3, RESTful API, and CLI, ensuring interoperability with existing data center management tools. This holistic approach supports proactive cooling strategies and helps maintain optimal operating conditions. Remote management is streamlined through Secure Array® IP Consolidation, which allows a single IP address to control up to 48 PDUs in an array. The built‑in web GUI and Power IQ® integration provide intuitive visualization of power trends and alerts. Together, these features enhance data center power reliability, improve efficiency, and protect valuable IT investments.
