Switched Pro eConnect PDU; Black; Vertical; For 42U or Higher Cabinets; 208V 3P/50A/CS8365 Input; (12) C13+(12) C19 Outlets; 14.4kW; 149°F (65°C); Secure Array IP Consolidation; Phase-Balance Locking Outlets; Field-Replaceable Controller; +/-1% Metering Accuracy; LCD Display; 10/100/1000MB Port; Onboard GUI; SNMPv1/v2/v3; LDAP or Radius Integration; HTTPs; Environmental Sensor and Electronic Lock Integration Ready; 100% Rated Hydraulic Magnetic Breakers; Toolless Mounting

MSRP $3,765.42
PlugCS8365C
Outlets(12) C13 Locking + (12) C19 Locking Outlets
Volts208V
PhaseThree-Phase
Input Current50A
kW Capacity14.4kW
Cabinet Compatibility42U or Higher
ColorBlack
Product Description

Switched Pro eConnect® PDUs provide remote power monitoring and control for each outlet on the PDU, making it possible to remotely measure and cycle power for each piece of equipment attached to the PDU.

Key Features and Benefits
  • Reduced Networking Costs and Complexity – Secure Array® allows the use of a single IP address for up to 48 connected PDUs (32 when electronic locks are integrated). Second IP address for the entire array provides failover capability.
  • Resistance to High Temperature – Marketleading temperature ratings of up to 149°F (65°C) ensures reliability when mounted toward hot aisles.
  • Simplified Load Balancing – Phase-balance outlets on three-phase models ensure equal loading across all phases; allows use of shorter equipment power cords for better cable and airflow management.
  • No Accidental Disconnections – Patented, low-profile locking outlets prevent accidental disconnections without requiring special cords
  • Easy Identification of Failover Unit – Redundancy Pack includes 2 PDUs (one in Black and one in Glacier White) for easy identification of the primary and secondary unit.
  • Electronic Lock Integration – Patented technology seamlessly integrates PDU, environmental sensors and electronic locks into a single hardware and software solution.
  • Gigabit Ethernet – Ensures compatibility with enterprise routers and switches.
  • Latest UL Compliance – Meets UL and IEC 62368 for compliance with new listing requirements for North America and the European Union.
  • Cabinet Preinstallation – Complete ecosystem ships ready for IT equipment integration, and saves deployment time and reduces packaging waste.
  • High Power Configurations – Configurations supporting up to 100A Input provide an optimized solution for GPU & AI based applications. 30A branch circuit breakers provide flexibility when plugging high power IT equipment.
  • Universal Input – A single PDU design with detachable input cords supports global AC power standards, streamlining procurement reducing inventory complexity, accelerating deployment, and ensuring reliable high-power performance across worldwide data centers.
What This Page Covers

Key Benefits of the EA-6027-C Switched Pro eConnect PDU

The Switched Pro eConnect® PDU EA-6027-C delivers intelligent power distribution for modern data‑center environments. With 6027‑level monitoring, each outlet provides real‑time voltage, current and power measurements that can be accessed through an onboard GUI or SNMP. Remote outlet control enables administrators to power‑cycle equipment without physical intervention, reducing service‑time and improving uptime. Detailed part number 6027 specifications show a 14.4 kW capacity, 208 V three‑phase input and a total of twelve C13 locking and twelve C19 locking outlets. The unit incorporates a +/-1 % metering accuracy and an LCD display that presents key metrics at a glance. All components are field‑replaceable, ensuring long‑term serviceability and minimal total cost of ownership. The PDU leverages Secure Array® IP consolidation, allowing up to 48 PDUs to share a single IP address while providing automatic fail‑over. Its phase‑balance locking outlets distribute load evenly across all three phases, which helps maintain optimal temperature and airflow in high‑density racks. The design is rated for operation up to 149 degreesF (65 degreesC), making it suitable for hot‑aisle deployments. Enterprises deploying AI, high‑performance computing or GPU‑intensive workloads benefit from the PDU's high‑current branch circuit breakers and 10/100/1000 Mbps Ethernet connectivity. For organizations that prefer flexible financing, the EA‑6027‑C is also available as pdu equipment for rent through authorized distributors, enabling rapid scaling without capital expense. Integrated LDAP, RADIUS and SNMPv3 security ensure that access controls meet strict compliance requirements. Partnering with CPI provides access to expert consultation services that can tailor the EA‑6027‑C to specific rack configurations and cooling strategies. The unit ships ready for cabinet pre‑installation, reducing deployment time and packaging waste. Contact a CPI sales specialist today to explore how this Switched Pro eConnect® PDU can enhance power reliability across your infrastructure.
