VL1500A

VL1500A - Thumbnail 1
VL1500A - Thumbnail 2
VL1500A - Thumbnail 3

1500VA/1350W Lead Acid Line-Interactive UPS; 2U; Single-Phase; 120V; 4 min Full Load Runtime; 6'L (1.8 m) Input Cord with 5-15P; (8) 5-15R Outlets; Smart LCD Screen; TAA Compliant; 3 Year Full Warranty; 3.5"H x 17.2"W x 18.9"D (89 mm x 437 mm x 481 mm); Black

MSRP $1,613.76
VA Capacity1500VA
Capacity Watts1350W
External Battery OptionY
Input Plug5-15P
Nominal Input Voltage120V
Output Receptacles(8) 5-15R
Runtime 100% Load4 minutes
Runtime 50% Load12 minutes
Product Description

VL Series — Reliable and economical backup power protection for servers and network applications.

Key Features and Benefits
  • Pure Sine Wave Line-Interactive Conversion— Provides robust power protection against blackouts, brownouts and voltage surges
  • 99% efficient operation—high efficiency ECO mode lowers energy consumption
  • Auto restart—Automatically restarts when utility power returns after full battery discharge
  • Smart LCD display—vital monitoring and precise information from the front panel
  • Programmable receptacle group—maximize uptime for critical loads and equipment by shedding less critical loads
  • Temperature compensation—temperature compensated charging to prolong battery life and help reduce replacement costs
  • Hot swappable battery—easy to replace without interrupting the load
  • Maintenance bypass—an optional maintenance bypass distribution module enables the UPS to be replaced or serviced without interruption of power to critical loads
  • Extended battery runtimes—optional matching battery modules available for extended runtimes

Additional Features

  • Available models: 800VA, 1100VA, 1500VA, 2000VA, 2200VA, 3000VA, 5000VA
  • Tower, two-post, and four-post rack mounting configurations
  • UL, cUL, CE, RoH, TAA Compliant
  • 3 years electronics, 3 years battery warranty (USA and Canada)
What This Page Covers

Advanced Features and Benefits of the VL Series UPS

The VL1500A is part of the Lead Acid Line-Interactive UPS series, which includes customized 800VA UPS models designed for robust power protection. This series offers smart retrofit solutions that enhance existing infrastructure without major overhauls. Models like the VL888 and VL1500A provide reliable backup for servers and network applications, ensuring continuous operation during outages.

Key features include pure sine wave line-interactive conversion, which safeguards against blackouts and voltage surges. The UPS achieves 99 percent efficiency in ECO mode, reducing energy consumption and operational costs. Auto restart functionality automatically powers equipment when utility power returns after a full battery discharge, minimizing downtime.

Users benefit from a smart LCD display that provides vital monitoring and precise information for easy management. Programmable receptacle groups allow prioritization of critical loads, maximizing uptime for essential equipment. Temperature compensation prolongs battery life, helping to reduce replacement costs and maintain performance.

The smart retrofit solution integrates seamlessly with existing systems, offering hot-swappable batteries for easy replacement without interrupting loads. Optional maintenance bypass distribution modules enable UPS servicing without power interruption to critical devices. Extended battery runtimes are available through matching battery modules, catering to diverse operational needs.

Chatsworth Products delivers these customized 800VA UPS options with global availability and rapid customization, supporting applications from data centers to industrial environments. The VL series, including the VL1500A and VL888, is UL, cUL, CE, RoHS, and TAA compliant, ensuring high standards of safety and reliability. With a 3-year warranty on electronics and batteries, CPI provides dependable power protection solutions.
